4506

STAINLESS BRAKE PINS
The SBS stainless brake pin range covers the most common MX and Enduro bikes from the early 1990s until today.
The range comprises 5 complete sets, front and rear together, but are also available as single packs with only front or rear to the respective model. Brake pad pins get wear grooves after a while so it is recommended to replace them regularly in order to prevent stiction and poor performance.

  • Made of high quality stainless steel 304
  • 8 mm hex head for quick and easy change of brake pad (excl. ref 4003)
  • Corrosion resistant
  • Smooth sliding between pin and brake pads

Specifications

Product type Brake Pins
Quality Brake Pins
Catalog number 4506

Fitment listing

Brand Model Use CCM Year Select
HONDA CR R Brake pin front 125 2002 - 2007
HONDA CR R Brake pin front 125 1998 - 2001
HONDA CR R Brake pin front 250 1995 - 2001
HONDA CR R Brake pin front 250 2002 - 2007
HONDA CRF R Brake pin front 250 2004 - 2020
HONDA CRF R Brake pin front 450 2002 - 2018
HONDA CRF RX Brake pin front 450 2017 - 2018
HONDA CRF X Brake pin front 250 2004 - 2014
HONDA CRF X Brake pin front 450 2005 - 2018
KAWASAKI KX Brake pin front 125 1995 - 1996
KAWASAKI KX Brake pin front 250 1995 - 1996
SUZUKI RM Brake pin front 125 1999 - 2004
SUZUKI RM Brake pin front 125 2005 - 2009
SUZUKI RM Brake pin front 250 1999 - 2004
SUZUKI RM Brake pin front 250 2005 - 2009
SUZUKI RM-Z Brake pin front 250 2007 2007
SUZUKI RM-Z Brake pin front 250 2008 - 2018
SUZUKI RM-Z Brake pin front 450 2005 - 2007
SUZUKI RM-Z Brake pin front 450 2008 - 2018
YAMAHA WR F Brake pin front 250 2003 - 2013
YAMAHA WR F Brake pin front 450 2003 - 2018
YAMAHA YZ Brake pin front 85 2010 - 2019
YAMAHA YZ Brake pin front 125 1998 - 2018
YAMAHA YZ Brake pin front 250 1998 - 2018
YAMAHA YZ F Brake pin front 250 2001 - 2018
YAMAHA YZ F Brake pin front 400 1998 1998
YAMAHA YZ F Brake pin front 426 2000 - 2002
YAMAHA YZ F Brake pin front 450 2003 - 2009
YAMAHA YZ FX Brake pin front 250 2015 2015
